.All. Onda Tablet Firmware Update Walk-Through Discussion in 'Onda Tablet Forum' started by iiDiabolusZz, Nov. Hey can anyone help my onda v971 is stuck in boot loop after trying to install the Jb are there any solutions? A software installation programe callled Phoenix Suite pack which I suppose this is the USB installation, and there. Onda USB devices Drivers Download. This page contains the list of download links for Onda USB devices. To download the proper driver you should find the your device name and click the download link. If you could not find the exact driver for your hardware device or you aren't sure which driver is right one, we have a program that will detect.
Hey guys, I was hoping that someone could help me out. I have an ONDA V711D V1 and I accidentally flashed the wrong firmware and wifi and accelerometer didnt work. I couldn't get Windows to recognize the tablet but finally after many many hours of trying I eventually opened the tablet to short out the TF-Pins and cut the Red Battery Wire and yesterday I had gotten Windows to finally recognize it as M6 and I installed the 'World Cup Device' driver.
Not sure if it matters, but I had taped the Home button in because I had no way to do everything at once (Short Pins with metal, and press Home + Power buttons all at once). Taping the Home button in, I was able to test out each and every pin until Windows finally recognized it. I then used AML Flash Tool to attempt to flash the 'V711Dv2.0.rar' firmware for V1 tablets and no matter what it keeps stopping at 75% (home button was held in the whole time during flash because i forgot to take the tape off). At this point, and Im not really sure if it is normal or not, but I can unlug and plug the tablet in without pressing any buttons and it always detects 'World Cup Device' in Windows XP.
I have a black screen and no backlight. I left it overnight unplugged and tried again this morning and the same thing happened without having to press anything. World Cup Device is detected and the flash stops at 75%. I am using Windows XP S3 Black Edition in English and in Device Manager, unchecked the 'power save' for all USB Root Hubs. Not sure is Black Edition matters as well.
Here is my log. If anybody could help me out it would be much muuuuch appreciated. I just wish I can get it working again, like normal.
Driver Usb Onda V971
Thanks so much. If I am leaving out any helpful info please let me know.
Thanks again. E/ P508:46:06failed because no connected device,current step is 18/code Hi CK420 Maybe this is better news – i was stuck on process 18, 75%. And i'm using a French edition of Windows 7 64 bit, which goes against the odds, AND i got the aml tool to work. I used the download from Onda.cn, their Vi40v2 - for my Vi40 dual core, in which their document advises - turning off the anti-virus and not having anything connected via USB except the tablet.
The trick is to right click on the file - ImageburnTool.exe - where window's menu gives you the option of opening the software 'as an administrator.' ( I don't get offered this option using the aml download from Slate, it's configured a little differently from the Onda download. On my Win 7, at least.) I did it this way and the software behaved totally differently.
First time round it went to stage 21 and then stopped there. Two days later i tried it again and it did it 100%. As i understand it, this is what they call 'buggy' software – it behaves differently at times, for no predictable reason. The other thing in it is that, at stage 18, the aml tool opens up the 16gb (maybe yours is 32gb) drive of the tablet, and i looked at this at the time it succeeded, there was a zip file there (if i remember correctly, it's difficult for me to note the details of this stuff ) and i think maybe that file took it through the last stages. Whole process was about 10 minutes.
In respect of you message (i'm no expert though) once your computer has loaded the driver called 'the world cup', it does not need to reload it the next time the tool is used. Best of luck. Hello everybody, hello Valkoz I know this is an Onda specific thread, but I have a hard bricked Gemei G6T-K8, that is an AML8726-MX based tablet too. The device is recognized correctly by WordlCup drivers and AML Burning Tool and the whole process is clear. My issue is that I have only the stock firmwares at hand, but they don't have a configprogress file in them.
Those firmwares where ment to be flashed through an sd card. Is there any way I can convert those images (eg. Edit a configprogress file by myself) to be used in AML Burning Tool?
Anyone has an AML rescue firmware for Gemei G6 - G6T - K8? Any pointer would be greatly appreciated!
Hello, i had to register to ask few questions because im stuck with something, i´ve done many things myself by reading around researching and so on. I have tablet labeled as Sencor Element 10.1 with Amlogic 8726-MX pics: after unsucessful updating i´ve bricked it to point without backlight/contrast blackscreen and no boot / turn on signs. I followed the total-brick guide here: i´ve got to the point where it was like described: 'Progress bar will reach abuot%, then you will see the error. It is normal.' - check, this happened after previous steps 'After some time (from 30 sec up to 2 min) you will see TWRP recovery menu on your tablet pc display' - nope, i am stuck here, nothing goes on on tablet and its still in non-bootable state needles to say, i am doing it on WinXP laptop since my Win8.1 PC refused to install Worldcup driver can someone help me resolve this? Hi, I bought this receiver: link removed by moderator and I installed wrong firmware and now I don't have CWM and appear only blue led. I tried several times and pressed reset button too many many times and different recovers.
I think only jtag to write flash again. But I don't know how. My receiver is Amlogic 8726-M3. I used this informations to recovery using SD card: 'Copy amlautoscript, uImagerecovery (renamed recovery.img), fw of you choice on FAT partition of prepared sdcard plug in box while holding reset button' My receiver has reset button and I don't know if is the same pins on motherboard. I used different u-boot.bin and recovery (sdcardmaker, HDDRawCopy1.02Portable) with some images too.
Used this informations too: 'amlogic boxes can boot recovery image from sd. On most boxes you have to prepare sd with SDcardmaker and your box related (or near related) uboot.bin put on the by SDcardmaker created FAT32 patition: recovery.img (or rename uImagerecovery ) and update.zip, boot with reset pressed.' No sucess too.
I think now is ony by JTAG, but I don't know where I find the softwares. I bought on aliexpress USB to TTL protocol but only few days I'll receive. See the motherboard: Sorry my english.
Thanks Edited by mrsburnout, 02 February 2014 - 11:30 AM. Re-direct not allowed - removed by admin. Thank You Valkoz, the screenshots were exactly what I needed to understand my mistake: I was trying to use no the whole Resources Zip, but the zips inside instead. After a few hours of google-and-slatedroid surfing found enough info to flash my Onda VI30D.
As I said, did it wrong. So, after re-trying it was soft bricked. But, as if it was not bad enough, I did it all again and hard bricked it:/ Following the guide for Elf II, using Crystal Recovery I was able to bring it back, but there was an issue with the video: the display was wrong, because it showed like a 7' screen and like when you move the image on a CRT monitor and the image is like folded on the side. The touch response was horrible, mirrored and like 2' from where I was touching. All that with the crystalbatch10928rescue. So, to go back to onda FW, my Solution was: erase nand using AMLFlashTool, then flashed Resource.Vi30Dv2.0 (As I said, this time I've selected the whole Resource.Vi30Dv2.0.zip, instead of the update.zip inside of it).
I´m sharing this with you, because I wasn´t able to find info about another case like mine, I mean, 'A fool, and his almost-dead twisted-display-tablet' Again THANK YOU Valkoz, wish you godspeed!
Tips: (vidi stranu 8 / ) Please carefully read the end of this tutorial, and then hands!!! Brush preparation: 1, please use the desktop computer WinXP or Win7 (32 -bit) systems, and turn off antivirus software ( part of the anti-virus software will likely upgrade tool in a v irus file false documents, and directly delete ). 2, the computer 's USB interface can not be occupied by other devices, if your computer is also connected with a USB keyboard or mouse, you need to do first before you can brush set as follows: 1 ) Right My Computer, select Device Manager, open the Universal Serial Bus controllers 2 ), select 'USB Root Hub', right click and select Properties, then on the pop-up menu of the tab to switch to the 'Power Management' in this column, remove the ' Allow the computer to turn off this device to save power ' in front of the check mark. 4, click on the upper left corner of the tool configuration - Import upgrade file option, choose to upgrade the firmware package ( Note: This firmware package is above the second step directory zip format file, select the file directly, as shown in V97 1 dual-core. Firmware for example ).
5, choose a good after firmware interface as shown below, at the bottom of t he tool will display the firmware load information: 6, flat first off ( if you are unsure what state the machine can short press the reset button to force shutdown ), then press and hold the Home key ( there is a small house on the key icon ) and hold.
